Seam Roofing System
The standing seam metal roof is one of the most exciting breakthroughs in roofing technology in the last 25 years. It fulfills the building owner’s need for durable, puncture-resistant protection against the weather, while working in concert with the forces of nature.
Why EUROWAVE®?
- German technology for a roof with exceptional performance
- i. First in Sabah
- ii. Leak proof
- Flexible design, giving outstanding appearance with excellent weathering protection.
Specifications
| Steel Grade | Base Metal Thickness (mm) | Total Coated Thickness (mm) | Mass (kg/m2) | Width Coverage (mm) | Depth of Rib (mm) |
|---|---|---|---|---|---|
|
G300 |
0.48 |
0.54 |
4.9 |
200 – 560 |
25 |
- Recommended Pitch 1° Minimum
- Recommended Radius Curve: 6m Minimum
- Maximum Recommended Support Spacings
| Roof | Max Roof Overhang Unsupported (mm) | ||||
|---|---|---|---|---|---|
|
End Span (mm) |
Continuous Span (mm) |
||||
|
600 |
600 |
50 |
|||
Front Elevation
CITY SEAL® PLUS
PE Seam Roofing System
Specifications
- PE Foam + Aluminized Polyester Film Facing
| Thickness (mm) | Thermal Conductivity (Kcal/mh°C) | Density (g/cm3) | Water Resistant | Weather Proofing | Chemical Resistant |
|---|---|---|---|---|---|
|
2 |
0.029 |
0.025 |
✓ |
✓ |
✓ |
